Stump cutters driven by

Hydraulic

  /    /  Hydraulic

Showing all 9 results

  • FSI H20

    Learn more
    FSI H20
    FSI 21 - 12 pcsMax 2.5 cm per sweep70 kg
    1.5 - 2.5 ton12-22 kW / 15-30 HP30-50 l/min @ max 250 bar
    • Hydraulic drive for 30-50 l/min
    • Including hydraulic hoses
    • Including uncoated top plate to weld on the tool grip.
    • Requires free flow return to the tank (leak oil)
    • Cutter wheel diameter: 386 mm
    • Free choice of cutting direction
    • Grinding moment performed via the carrying machine

  • FSI H20S

    Learn more
    FSI H20S
    FSI 21 - 12 pcs94 cmMax 2.5 cm per sweep92 kg
    1.5 - 2.5 ton12-22 kW / 15-30 HP30-50 l/min @ max 250 bar
    • Hydraulic driven stump grinding with integrated sweep movement
    • Uncoated backplate to which an attachment can be fitted (FSI can supply adaptor bracket fitting the most common machines)
    • Including hydraulic hoses
    • FSI HxxS stump cutters require a free-flow return to the tank (leak oil).
    • Cutting head diameter: 386 mm
    • Sweep width: 940 mm
    • Connections: Pressure, return, leak oil

  • FSI H40

    Learn more
    FSI H40
    FSI 25 - 16 pcsMax 5.2 cm per sweep150 kg
    3.0 - 7.0 ton18-31 kW / 25-42 HP50-75 l/min @ max 250 bar
    • Hydraulic drive for 50-75 l/min
    • Including hydraulic hoses
    • Including uncoated top plate to weld on the tool grip.
    • Requires free flow return to the tank (leak oil)
    • Cutter wheel diameter: 470 mm
    • Free choice of cutting direction
    • Grinding moment performed via the carrying machine

  • FSI H40S 50-75

    Learn more
    H40-S Left angle
    FSI 25 - 16 pcs118 cmMax 5.2 cm per sweep200 kg
    1.5-2.5 t 18-31 kW / 25-42 HP50-75 l/min @ max 250 bar
    • Hydraulic driven stump grinding with integrated sweep movement
    • Oil flow 50-75 l/min
    • Uncoated backplate to which an attachment can be fitted (Adaptor bracket range FSI – for most common)
    • Control of the sweeping movement can be done either from the tool
      carrier or by an electronic control box.
    • Including hydraulic hoses
    • FSI HxxS stump cutters require a free-flow return to the tank (leak oil).
    • Cutting head diameter: 470 mm
    • Sweep width: 1180 mm
    • Connections: Pressure, return, leak oil

  • FSI H40S 80-110

    Learn more
    FSI H40S 80-110
    FSI 25 - 16 pcs118 cmMax 5.2 cm per sweep250 kg
    1.5 - 3.5 t 29-48 kW / 40-65 HP80-110 l/min @ max 250 bar
    • Hydraulic driven stump grinding with integrated sweep movement
    • Oil flow 50-75 l/min
    • Uncoated backplate to which an attachment can be fitted (Adaptor bracket range FSI – for most common)
    • Control of the sweeping movement can be done either from the tool
      carrier or by an electronic control box.
    • Including hydraulic hoses
    • FSI HxxS stump cutters require a free-flow return to the tank (leak oil).
    • Cutting head diameter: 470 mm
    • Sweep width: 1180 mm
    • Connections: Pressure, return, leak oil

  • FSI H52

    Learn more
    FSI H52
    FSI 25 - 20 pcsMax 6.1 cm per sweep220 kg
    8.0 - 14.0 ton29-48 kW / 40-65 HP80-110 l/min @ max 300 bar
    • Hydraulic driven for 80-110 l/min
    • Cutter wheel diameter: 580 mm
    • Free choice of cutting direction
    • Attached using tool grip/coupling
    • Uncoated top plate to weld on tool grip
    • Grinding moment performed via the carrying machine
    • Requires free flow return to the tank (leak oil)

  • FSI H65 100-130

    Learn more
    FSI H65 Right-angled view
    FSI 29 - 28 pcsMax 8.2 cm per sweep500 kg
    12.0 - 20.0 ton55-77 kW / 75-100 HP100-130 l/min @ max 350 bar
    • Hydraulically driven stump grinder –oil flow: 135-160 l/min
    • Chip guard
    • Uncoated top plate to weld on the tool grip
    • Attached using a tool grip/coupling
    • Grinding movement performed via the excavator
    • Require free flow return to the tank (leak oil)

  • FSI H65 135-160

    Learn more
    FSI H65 135-160
    FSI 29 - 28 pcsMax 8.2 cm per sweep500 kg
    12.0 - 20.0 ton77-92 kW / 105-125 HP135-160 l/min @ max 350 bar
    • Hydraulically driven stump grinder –oil flow: 135-160 l/min
    • Chip guard
    • Uncoated top plate to weld on the tool grip
    • Attached using a tool grip/coupling
    • Grinding movement performed via the excavator
    • Require free flow return to the tank (leak oil)

  • FSI H65 165-200

    Learn more
    FSI H65 165-200
    FSI 29 - 28 pcsMax 8.2 cm per sweep520 kg
    12.0 - 20.0 ton92-118 kW / 125-160 HP165-200 l/min @ max 350 bar
    • Hydraulically driven stump grinder –oil flow: 165-200 l/min
    • Chip guard
    • Uncoated top plate to weld on the tool grip
    • Attached using a tool grip/coupling
    • Grinding movement performed via the excavator.
    • Require free-flow return to the tank (leak oil)
