Stump grinder for PTO (35-80 hp)

FSI T27

  /    /  Tractor  /  FSI T27

FSI T27

FSI T27 is for mounting on tractors and similar machines with power take-off (PTO) ranging from 35-80 HP.

The frame for 3-point linkage (Cat. 1 & 2) is equipped with adjustable support legs, which ensure stability during stump cutting.

During work, the movements of the stump cutter are controlled directly from the joystick, located on the movable control box. The sweep speed of the stump grinder can be adjusted with a throttle valve, also located on the control box. You therefore have all necessary functions available right at hand for convenient operation.

Moving the joystick controls the cutter head movements from side to side, as well as up and down. The buttons on the joystick are used to move the cutter head back and forth on the arm, allowing you to cut larger stumps without having to move your tractor.

The stump grinder is supplied with PTO shaft, joystick and an extra bracket for the valve box, allowing you to place it on or near the tractor as desired.

FSI T27 is supplied for tractors and tool carriers with 540 RPM power take-off.

FSI 25 - 16 pcs.140 - 175 cmMax 4.3 cm per sweep40 cm
40 cm360 kg27-60 kW / 35-80 HP35 l/min. @ max 180 bar

Quick info

  • 3-point linkage (Cat. 1 & 2)
  • PTO power transmission (540 RPM)
  • T-Gear and V-belt drive for optimal power transmission
  • Electro-hydraulic joystick with full control
  • Control box with extra bracket for mounting on tractor
  • Hydraulic extension of the cutter head
  • Adjustable support legs
  • Tool set
